6Operation
CyFlow
®
Cube 8 | Operating Manual | May 2018 | Revision 032 31
Creating a new Worklist
Requirements
To create a Worklist for future measurements, login as an assay
developer is necessary.
Procedure
1. On the File tab of the Ribbon (see chapter 12.4.1 File tab on page 58)
select "File > New > New Worklist".
In Worklist mode, a new Worklist can also be created by clicking the New
button in the Worklist pane (see chapter 12.6 Worklist pane on
page 146).
– A new default Worklist containing 400 blank Worklist items is created
and displayed in the Worklist pane.
– The software is in Worklist mode.
Defining a new Workspace
A Workspace contains the plots, regions and gates of interest (see chapter
12.8 Workspace on page 160). To prepare a new measurement, a
Workspace can be prepared before acquiring data and further adapted while
measuring a sample.
Procedure
1. Double-click a Worklist item to open it in the Workspace.
2. In the Worklist, enter a Lab # and sample ID for the Worklist item as
desired.
3. Define which plots to be displayed in the Plots area of the Workspace:
On the Home tab of the Ribbon (see chapter 12.4.2 Home tab on
page 65), click the Density Plot button or the Histogram Plot button to
add a corresponding plot to the Workspace.
Alternatively, select the desired plots by double-clicking on the plots in
the Previews area of the Workspace.
4. To change the parameter for an axis of a plot, right-click on the axis and
select the parameter from the drop-down list.
Alternatively, select the parameter from the Parameters group of the
Home tab of the Ribbon (see chapter Parameters group on page 66).
5. To change the scaling of the axes, select a plot, then select the scaling
(linear or logarithmic) on the Parameters group of the Home tab.
6. To change the plot title, double-click the current plot title and enter a new
title.
– A new Workspace is defined.
