11 Technical data
48 CyFlow
®
Cube 8 | Operating Manual | May 2018 | Revision 032
Optics (dependent on system configuration)
Laser output V1: Blue laser 488 nm 50 mW
V2: Blue laser 488 nm 50 mW, Red laser 638 nm
25 mW
V4: Blue laser 488 nm 50 mW, Red laser 638 nm
25 mW, UV-LED 365 nm
V5: Violet laser 405 nm 100 mW, Blue laser 488 nm
50 mW, Red laser 638 nm 25 mW
V6: UV laser 375 nm 60 mW, Blue laser 488 nm 50 mW,
Red laser 638 nm 25 mW
V7: Blue laser 488 nm 50 mW, Yellow laser 561 nm
100 mW, Red laser 638 nm 25 mW
V8: Blue laser 488 nm 50 mW, Red laser 640 nm
40 mW
V9: Blue laser 488 nm 50 mW, UV-LED 365 nm
V10: Blue laser 488 nm 50 mW, Orange laser 594 nm
50 mW, Red laser 638 nm 25 mW
V11: Violet laser 405 nm 100 mW, Blue laser 488 nm
50 mW
N1: Blue laser 488 nm 50 mW, Red laser 640 nm
40 mW
Laser class Laser class I
(Laser class IIIb if device is opened and laser protection
is removed)
Detectors V1: 1 to 5 (FSC, SSC, FL1, FL2, FL3)
V2: 1 to 6 (FSC, SSC, FL1, FL2, FL3, FL4)
V4: 1 to 8 (FSC, SSC, FL1, FL2, FL3, FL4, FL5, FL6)
V5: 1 to 8 (FSC, SSC, FL1, FL2, FL3, FL4, FL5, FL6)
V6: 1 to 8 (FSC, SSC, FL1, FL2, FL3, FL4, FL5, FL6)
V7: 1 to 8 (FSC, SSC, FL1, FL2, FL3, FL4, FL5, FL6)
V8: 1 to 7 (FSC, SSC, FL1, FL2, FL3, FL5, FL6)
V9: 1 to 6 (FSC, SSC, FL1, FL2, FL3, FL5)
V10: 1 to 8 (FSC, SSC, FL1, FL2, FL3, FL4, FL5, FL6)
V11: 1 to 8 (FSC, SSC, FL1, FL2, FL3, FL4, FL5, FL6)
N1: 1 to 6 (FSC, SSC, FL1, FL2, FL3, FL4)
Filters Standard setup and filters for all parameters according
to laser configuration
Optical coupling Standard objective mount with high numerical aperture
objective, high numerical aperture immersion gel
coupling, e.g. for detection of weak cytokines (option)
Excitation optics Elliptical 15 μm × 100 μm at 488 nm, other beam
geometries upon request
