12 Software description
CyFlow
®
Cube 8 | Operating Manual | May 2018 | Revision 032 61
Export
The Export menu is only available in Playlist mode except for the Export
Report to PDF menu item which is also accessible in Worklist mode.
The menu contains the following options:
Export Statistics to CSV: This menu item is only enabled when there
are results present in the results table. The results exported to a CSV file
are the columns displayed in the results table in the Results tab of the
Workspace. The format of the export is either single row per file or one
row per result, depending on the selection in the software options (see
chapter 12.10 CyFlow Options on page 187). Click the menu item to save
a CSV formatted file containing the results of the currently open Playlist
item only. A dialogue box appears. Enter a name for the export, select
the destination folder and click the Open button.
If the entered file name already exists and the format of the exported
data matches the formatting of the data in the file, the results are
appended to those already in the file.
If the entered file name already exists but the headers in the two files do
not match, you will have the option to overwrite the existing file. After the
file has been saved, the Windows Explorer opens with the exported file
highlighted.
Export All Statistics to CSV: This menu item is only enabled when
there are results present in the results table in the Results tab of the
Workspace. Click the menu item to save a CSV formatted file containing
the results of all files in the Playlist. A dialogue box appears. Enter a
name for the export, select the destination folder and click the Open
button.
If the entered file name already exists and the format of the exported
data matches the formatting of the data in the file, the results are
appended to those already in the file.
If the entered file name already exists but the headers in the two files do
not match, you will have the option to overwrite the existing file. After the
file has been saved, the Windows Explorer opens with the exported file
highlighted.
Export Playlist: This menu item is for exporting a Playlist for sharing
with other users and colleagues or for archiving. Any modifications to the
Playlist need to be saved before it can be exported.
Click the menu item and select the destination folder for the export.
Click the OK button to perform the export. A folder with the same name
as the current Playlist is created inside the destination folder. The
exported Playlist is placed in it. The exported listmode files are placed in
a subfolder called "LMD". The exported image files are placed in a
subfolder called "Images". Worklist and compensation files are stored as
part of the Playlist file (XMLP file).
