EXCITE + - Crossover: Technical Service guide- Ver. 4.1
Page 6.35
Check if the +5Vdc are at the
input of the Receiv er Board.
Are present?
ARM/CPU Board
def ectiv e.
Replace it.
3
NO
YES
Check if the +5Vdc are at the
output of the ARM/CPU Board.
Are present?
4
NO
Replace the cable.
A
Receiv er Board def ectiv e.
Replace it.
YES
Continued on following page ...
