Technogym EXCITE+ - And 700 SP Version

EXCITE + - Crossover: Technical Service guide- Ver. 4.1
Pagina 7.2
7.1.2. 700 AND 700SP VERSION
Figure 7.1-4
Turn off the machine a
nd unplug the mains lead
from the wall outlet:
1. Back off the 4 screws (a)
using a medium
Phillips screwdriver.
Figure 7.1-5
2.
Unplug the connector highlighted in the
figure at the side.
3. Remove the Display.
Figure 7.1-6
4. Back off the 2 screws (b), using an 8mm
hexagonal wrench, for remove the rear
support of the Display.
To reassemble the LED Display,
carry out the above steps in reverse order.
