EXCITE + - Crossover: Technical Service guide- Ver. 4.1
Page 6.25
6.12. THE RESISTANCE IS INCORRECT
The machine will produce an incorrect resistance if:
• the mechanical components are not in perfect condition;
• the speed measurement is incorrect;
• the Brake Board is defective;
• the brake is defective.
Are the mechanics of the
machine in g ood condition?
Does the Brake Board output
the correct current to the brake
winding?
Replace the Brake Board
NO
Replace the Brake
winding
YES
THE RESISTANCE IS
INCORRECT
2
Repair the faulty
mechanical parts
NO
Carry out the "Speed
signal is Incorrect"
troubleshooting procedure
3
Carry out the Standard Setting
procedure
1
YES
