Technogym EXCITE+ - ARM Board (A)

EXCITE + - Crossover: Technical Service guide- Ver. 4.1
Pagina 7.5
7.2.1.1. ARM board (A)
Figure 7.2-2
1.
Unplug the connectors highlighted in the
figure.
2. Back off the 5 screws (c) usi
ng a medium
Phillips Screwdriver.
1. Remove the ARM board (A).
To reassemble the ARM board,
carry out the above steps in reverse order.
