EXCITE + - Crossover: Technical Service guide- Ver. 4.1
Pagina 7.62
7.22. DISASSEMBLING THE POWER ENTRY MODULE
Only for models: POWERED.
Figure 7.22-1
Incline the equipment on a side with caution:
1. Unplug the cables (a).
2. Back off the 2 screws (b)
Phillip screwdriver.
3. Remove the power entry module (c).
For VISIO models:
4. Remove the antenna cable.
To reassemble the power entry module,
carry out the above steps in reverse order.
