6. TROUBLESHOOTING
The troubleshooting procedures are illustrated by means of flow diagrams. To facilitate
interpretation of these diagrams, the following standard box shapes are used:
START
This type of box is the START point of the troubleshooting
procedure. It typically contains a description of the problem or
malfunction.
Decision
This type of box represents a decision point in the troubleshooting
procedure. It typically contains a description of the CHECK to be
made, with an outcome that is either a positive (YES) or negative
(NO) response.
Action
This type of box is a step in the troubleshooting procedure where an
ACTION must be carried out. It typically contains a description of
the ACTION necessary to resolve the problem Therefore, after
executing the specified ACTION:
1. Check whether the problem has been resolved;
2. If the problem persists, it is recommended to resume the
troubleshooting procedure from the point before the action was
carried out.
Note
Clarification of the operation in progress or that will be below
1
A circled number (such as that shown on the left) next to a box of
the troubleshooting procedure indicates that more detailed
instructions for performing that particular check or action are
provided below the flowchart.
A
A circled letter (such as that shown on the left) is used to mark a
point in the procedure. Typically, this indicator is used in page
changes.
The connectors indicated in the following pages, refer to 700 powered models Boards,
unless otherwise indicated.
