EXCITE + - Crossover: Technical Service guide- Ver. 4.1
Pagina 8.4
8.2.2. TENSIONING A NEW BELT
Figure 8.2-4
WARNING: The right tension of belt
must be: 149Hz±10Hz
detected on the long arm of the belt, as
indicated by the yellow arrows in
figure at side.
Figure 8.2-5
2. Exercise at maximum level (liv. 25)
stressing the movement on the platforms and the body
centre of gravity from left to right side. If you feel like a “lack of braking” but the machine is not
able to lift you up (due to high brake effect) it means that what you feel like the lack of braking
is due to the belt slippage and not to problem to the brake.
3. Tighten the belt again and repeat the test at step (2) until the belt does not slip anymore.
