Technogym EXCITE+ - Disassembling the Battery

EXCITE + - Crossover: Technical Service guide- Ver. 4.1
Pagina 7.54
7.18. DISASSEMBLING THE BATTERY
Only for models: SELF-POWERED.
Figure 7.18-1
Carry out the procedure described in paragraph:
7.8.2. “Disassembling the lateral guards”.
1. Unplug the 2 fast-on (a).
2. Cut the cable-ties (b).
3. Remove the battery (c).
To reassemble the battery, carry out the above
steps in reverse order.
