EXCITE + - Crossover: Technical Service guide- Ver. 4.1
Pagina 7.25
Figure 7.5-3
5.
Unplug the junction connectors of the cables
which goes from the disp
lay to the lower
electronic.
6. Remove the column.
To reassemble the column,
follows the above steps in the reverse order.
During the reassembly: p
ay attention
the cables are properly connected
inside the frame, as shown in figure at
the side
