EXCITE + - Crossover: Technical Service guide- Ver. 4.1
Page 2.22
CU353: Generator cable (LED Only)
(Brake Board - Generator - Battery – Battery charge input)
Brake Board
CN3
Signal Colour Generator Battery
Battery charge
input
1
Battery V+
Red
-
Fas-ton
-
2
Tension V+ from battery
charge
Red -
welded to internal
contact
4
RPM Signal
White
Fast-on
6
Battery V-
Black
-
Fast-on
-
7
Tension V- from battery
charge
Black -
welded to internal
contact
8
Tension V- fron generator
Black
Fast-on
-
10
Tension V+ fron generator
Red
Fast-on
-
CU354: Display power supply lower cable
(Brake Board– Patch Conn.)
Brake Board
CN1
Signal Colour Patch Conn.1
1
n.c.
-
1
2
GND – 12V / p.u.
White
2
3
GND – 5V / 12V
Yellow
3
4
Sens. GND 5V
Pink
4
5
n.c.
-
5
6
+12V
Brown
6
7
+5V
Green
7
8
Sens. +5V
Grey
8
CU355: Display power supply upper cable
(Patch Conn. –CPU/ARM Board)
Patch Conn. 1 Signal Colour
CPU Board:CN15
ARM Board: CN1
1
n.c.
-
1
2
GND – 12V / p.u.
White
2
3
GND – 5V / 12V
Yellow
3
4
Sens. GND 5V
Pink
4
5
n.c.
-
5
6
+12V
Brown
6
7
+5V
Green
7
8
Sens. +5V
Grey
8
Frame
Earth
Receiver
Earth
Signal Colour
Display Earth
JP10
Fast-on
Fast-on
GND
Yellow/Green
Fast-on
