Data Input/Output
CSA7000B Series & TDS7000B Series Instruments User Manual
3- 243
Overview Control elements and resourcesTo save a waveform (Cont.)
Name the file 24. Select the file type in the Save as type drop-down list to
force the file listing to only include these types. Use
*.dat for waveforms.
Note. Only change the type if you want to temporarily
see any other types of files in the current directory.
Otherwise, leave it as set by the Export Setup control
window.
25. Specify the filename in which to save your waveform.
You can:
H Use the default name and directory appearing in
the File name field.
H Rename the file by typing a new name into the File
name field.
H Select the Auto-increment file name check box to
save a series of files without typing in a new name
each time. For more information, see Using
Auto-Increment File Name on page 3--222.
Note. If your instrument lacks a keyboard, touch or click
the keyboard icon buttons to display a virtual keyboard.
You can use the mouse or touch screen with the virtual
keyboard to type entries in the name fields.
Edit path and file name
Access to virtual keyboard
Save the file 26. Touch the Save button to save the file. To cancel without
saving a file, touch the Cancel button.
For further
assistance
27. For more help on exporting files, touch the Help
button to access contextual online help.
See page 3--263 to learn about using online help.
