Data Input/Output
3- 242
CSA7000B Series & TDS7000B Series Instruments User Manual
Overview Control elements and resourcesTo save a waveform (Cont.)
Export your file 21. To export the file, from the menu bar, select Export.
You can also attach the front-panel PRINT button to
Export. Then, pressing the PRINT button will export
your file. Do the following to attach the PRINT button to
Export:
H From the menu bar, select File, and then select
Export Setup to display the Export Setup control
window
H Touch Set Print button to Export
22. The Export window lists all available waveforms, allows
for browsing to the destination directory, naming the file,
and selecting the file format.
Select a
destination
23. Use the Save in: drop-down list and buttons to navigate
to the directory in which you want to save the file.
To Next Page
