Data Input/Output
CSA7000B Series & TDS7000B Series Instruments User Manual
3- 241
Overview Control elements and resourcesTo save a waveform (Cont.)
Setup to export
measurements
17. Select the Measurements tab to displ ay the Measure-
ments control window.
18. Touch Data Format, and select the data format (text or
numeric) from the list.
19. Select the Measurements that you want to export:
H Displayed Measurements exports measurements
that are displayed on screen
H Measurement s Snapshot exports a snapshot of all
measurements
H Histogram Data exports current histogram data
20. Touch OK to accept your changes, Cancel to close the
window without making changes, or Help to access
more information.
To Next Page
