Tektronix CSA7404B User Manual

Appendix A: Specifications
CSA7000B Series & TDS7000B Series Instruments User Manual
A-9
Table A- 2: Channel input and vertical specifications (Cont.)
Characteristic Description
Analog bandwidth with P7330 active probe,
typical
C
S
A
7
4
0
4
B
a
n
d
T
D
S
7
4
0
4
B
DC 50 Ω coupling, Full bandwidth, operating ambient 15 °Cto30°C, derated by
20 MHz/°C above 30 °C
CS
A
7404B
a
nd TDS7404B
SCALE range
Bandwidth
2mV/divto3.9mV/div DC to 1 GHz
4mV/divto9.9mV/div DC to 1.25 GHz
≥10 mV/div DC to 3.5 GHz
Analog bandwidth with P7260 active probe or
TCA-BNC adapter, typical
T
D
S
7
7
0
4
B
Operating ambient 15 °Cto30°C(59°Fto86°F) at V/div ≥10 mV/div, derated by
20 MHz/°C above 30 °C(86°F)
TDS7704B
SCALE range
Bandwidth
2mV/divto3.9mV/div DC to 1 GHz
4mV/divto9.9mV/div DC to 1.25 GHz
≥10 mV/div DC to 6 GHz
Calculated rise time, typical
1
TDS7704B 62 ps
CSA7404B & TDS7404B 100 ps
TDS7254B 130 ps
TDS7154B 200 ps
Step response settling errors, typical Full bandwidth
SCALE range and step amplitude Settling error at time after step
2 mV/div to 99.5 mV/div,
with ≤ 1.5 V step
20 ns: ≤ 2%
1ms:≤ 0.1%
100 mV/div to 1 V/div,
with ≤ 3Vstep
20 ns: ≤ 2%
1ms:≤ 0.2%
