Appendix A: Specifications
A-10
CSA7000B Series & TDS7000B Series Instruments User Manual
Table A- 2: Channel input and vertical specifications (Cont.)
Characteristic Description
Pulse response, peak detect, or envelope mode Sample rate setting Minimum pulse width
2.5 GS/s or less 400 ps
Position range ± 5 divisions
Offset range
SCALE range Offs et range
2mV/divto50mV/div ±0.50 V
50.5 mV/div to 99.5 mV/div ±0.25 V
100 mV/div to 500 mV/div ±5V
505 mV/div to 1 V/div ±2.5 V
n Offset accuracy Net offset is the nominal voltage that must be applied to the channel to bring the trace
to center screen. Net offset = offset -- ( position × volts/division). Offset accuracy is
the accuracy of this voltage level.
CSA7404B, TDS7404B, TDS7254B, &
SCALE range Offset accuracy
TDS7154B
2mV/divto9.95mV/div
±(0.2% ×| net offset | + 1.5 mV +
0.1 div ×V/div setting)
10 mV/div to 99.5 mV/div ±(0.35% ×| net offset | + 1.5 mV +
0.1 div ×V/div setting)
100 mV/div to 1 V/div ±(0.35% ×| net offset | + 15 mV +
0.1 div ×V/div setting)
TDS7704B SCALE range Offset accuracy
2mV/divto9.95mV/div ±(0.35% ×| net offset | + 1.5 mV +
0.1 div ×V/div setting)
10 mV/div to 99.5 mV/div ±(0.5% ×| net offset | + 1.5 mV +
0.1 div ×V/div setting)
100 mV/div to 1 V/div ±(0.5% ×| net offset | + 15 m V + 0.1 div
×V/div setting)
