Tektronix CSA7404B User Manual

Overview
3-2
CSA7000B Series & TDS7000B Series Instruments User Manual
Tasks or topics
Subtasks or subtopics Section title Contents Page no.
Signal Input Acquiring waveforms Acquiring Waveforms Overview of section contents 3--7
Signal Connection and
Conditioning
Overview of signal connection and
conditioning techniques and setups
3--8
To Set Up Signal Input Setting up signal input 3--12
To Autoset the
Instrument
Automatic setup of the acquisition,
triggering systems and input channels
3--15
To Reset the Instrument Resetting the instrument 3--16
To Get More Help Accessing the online help 3--16
Input Conditioning
Background
Background information on input signal
conditioning
3--17
Setting Acquisition
Controls
Background and setup of acquisition
controls and roll mode
3--23
To Set Acquisition Modes Set up of the acquisition system 3--29
To Start and Stop
Acquisition
Starting and stopping acquisitions 3--32
To Set Roll Mode Setting up roll mode 3--33
Acquisition Control
Background
Background information on acquisition
controls
3--34
Using Fast Acquisition
Mode
Overview and setup of Fast Acquisition
mode
3--40
To Turn Fast Acquisitions
On and Off
Turning fast acquisitions on and off 3--44
Using FastFrame Overview and setup of FastFrame 3--48
To Set FastFrame Mode Setting up FastFrame mode 3--50
Time Stamping Frames Setting up FastFrame time stamps 3--52
O/E Converter
CSA7000B Series only
Overview and reference to documentation
on using optical signals and the O/E
Converter
3--55
Front Panel Connectors
CSA7000B Series only
Overview of O/E Converter front-panel
connectors
3--56
Wavelength, Filter, and
Bandwidth Selection
CSA7000B Series only
Overview of optical controls 3--59
Optical bandwidth
CSA7000B Series only
Overview of optical bandwidth 3--60
