Tektronix CSA7404B User Manual

Overview
CSA7000B Series & TDS7000B Series Instruments User Manual
3-3
Tasks or topics
Page no.ContentsSection titleSubtasks or subtopics
Signal Input Triggering waveforms Triggering Background on basic trigger operation 3--63
Triggering Concepts Background on triggering concepts 3--64
Triggering From the Front
Panel
Using the front-panel edge trigger controls 3--68
Access Procedures Setting up triggers with front-panel
controls
3--68
To Check Trigger Status Checking trigger status 3--72
Additional Trigger
Parameters
Using additional trigger controls 3--73
Advanced Triggering Overview and setup for triggering on
specific pulse and logic conditions
3--77
To Trigger on a Glitch Setting up glitch triggering 3--83
To Trigger on a Runt Pulse Setting up runt pulse triggering 3--85
Trigger Based on Pulse
Width
Setting up pulse width triggering 3--87
To Trigger Based on
Transition Time
Setting up transition time triggering 3--89
Trigger Based on Pulse
Timeout
Setting up pulse timeout triggering 3--94
Trigger on a Pattern Setting up pattern triggering 3--95
To Trigger on a State Setting up state triggering 3--98
To Trigger on Setup/Hold
Time Violations
Setting up setup/hold time violation
triggering
3--99
Sequential Triggering Overview and setup for triggering after
time delay and triggering on events
3--103
To Trigger on a Sequence Setting up triggering on a sequence 3--109
Comm Triggering
(optional on TDS7000B
Series)
Overview and reference to documentation
on using communications triggering
3--117
Serial Pattern Triggering
(optional on TDS7000B
Series)
Overview and reference to documentarian
on using serial pattern triggering
3--117
