Tektronix CSA7404B User Manual

Overview
3-4
CSA7000B Series & TDS7000B Series Instruments User Manual
Tasks or topics
Page no.ContentsSection titleSubtasks or subtopics
Display Features Using the Display Displaying Waveforms Using display features and customizing
the display
3--119
Using the Waveform
Display
Overview of display features and setup of
the display
3--119
To Display Waveforms in
theMainGraticule
Display adjustments you can make 3--124
Setting Zoom Controls Overview and use of Zoom 3--125
To Zoom Waveforms Setup to zoom a waveform 3--126
Customizing the Display Customizing display elements 3--131
Set Display Styles Overview of display adjustments you can
make
3--135
Customize Graticule and
Waveforms
Overview of graticule and waveform
adjustments you can make
3--137
Data Processing
(
C
l
l
t
i
)
Taking Measurements Measuring Waveforms Setup for measuring parameters 3--139
(C
a
l
c
ul
a
tion)
Taking Automatic
Measurements
Overview and setup for taking automatic
measurements
3--140
To Take Automatic
Measurements
Set for automatic measurements 3--144
To Localize a
Measurement
Setup to measure a segment of a
waveform
3--149
Taking Cursor Measure-
ments
Overview and setup for taking cursor
measurements
3--151
To Set the Cursor Sources Selecting the cursor sources 3--155
Taking Histograms Overview and setup for taking Histograms 3--157
To Start and Reset
Histogram Counting
Setup for histogram counting 3--158
Optimizing Measurement
Accuracy
Increase accuracy by compensating the
instrument and adjusting deskew
3--160
To Compensate the
Instrument
Setup to compensate the instrument 3--160
