G10 Installation Guide 28
Version 7.13.2
Install Hardware and Power Cabling
005-140228
2
Figure 2.10 - Storage Enclosure Install, Four-Post Rack, Front Mount (36-inch Rack)
Figure 2.11 - Storage Enclosure Install, Four-Post Rack, Front Mount (1000 MM Rack)
Align 36” line on bracket
with rear of enclosure
Attach brackets to sides of enclosure with
eight Phillips flat-head screws at 36” lines
Storage Enclosure (Side View)
Align 1000 MM line on bracket
with rear of enclosure
Attach brackets to sides of enclosure with
eight Phillips flat-head screws at 36” lines
Storage Enclosure (Side View)
