Tektronix TBS1000C Series User Manual

3. Push the Multipurpose knob to select the other cursor (which becomes a
solid line), then turn the knob to move that cursor. The first cursor is now
drawn with a dotted line.
4. To make smaller cursor position adjustments, push the Function button to
toggle between making coarse and fine cursor position adjustments.
The Fine knob sensitivity in the Function button also enables smaller
adjustments on the Vertical and Horizontal Position knobs, the Trigger
Level knob, and many adjustment operations of the Multipurpose knob.
NOTE. You can also switch between Fine and Coarse by pressing and holding
the Multipurpose knob.
5. Push the Amplitude or Screen side-menu button to select a different cursor
for taking measurements. See Cursor types on page 105.
Analyzing a waveform
TBS1000C Series Oscilloscopes User Manual 103
