c. Push the Save As side-menu button.
d. Select and click USB File (*.ISF) or USB File (*.CSV) to save the
waveform data to an automatically named file on the USB drive . See
About waveform data files on page 131.
Saving oscilloscope setup information
You can save the oscilloscope internal settings to an internal memory location
(setup 1–10) or to an external file on the USB drive. A setup file contains most of
the oscilloscope settings, including vertical, horizontal, trigger, cursor, and
measurement parameters. It does not include communications information, such
as GPIB addresses. You can then use the setup data to quickly set the
oscilloscope to take a certain measurement.
Use this procedure to save the current oscilloscope settings to a memory location
or external file.
1. (Optional) Install a USB drive to save the setup data to a file on the USB
drive.
2. Push the Save Recall front-panel button.
3. Push the Action side-menu button.
4. Use the Multipurpose knob to select and click Save Setup.
Saving data
128 TBS1000C Series Oscilloscopes User Manual
