5. To save setup data to internal setup memory:
a. Push Save As side-menu button.
b. Use the Multipurpose knob to select and save the setup memory
location (1-10).
6. To save setup data to a file on the USB drive:
a. Push Save As side-menu button.
b. Use the Multipurpose knob to select and click USB File (*.SET file) to
save the waveform data to an automatically-named file at the top level of
the USB drive. See About automatically generated file names on
page 144
Saving files to USB with the Save File button
The Save button is a quick, one-push way to save a specified data files to the
USB drive. After you have defined the save parameters with the Save Recall
button and Action side-menu button, you can assign that save action to the Save
File button. For example, if you assign Save to write waveform data to a USB
drive, then each push of the Save button saves the current waveform data to the
USB drive.
NOTE. The Save button only saves files to the USB drive. You cannot assign the
Save button to save information to reference or setup memory, or to recall files
from the USB drive.
NOTE. The oscilloscope saves files to the top level of the USB drive by default.
You can use the Change folder button in the File Utility side menu to set the
oscilloscope to save files to a specific location on the USB drive. See Changing
the default file save location on the USB drive on page 139.
Files are saved to the USB drive using a specific naming convention. See About
automatically generated file names on page 144.
