Tektronix TBS1000C Series User Manual

5. To recall setup data from internal setup memory:
a. Push the Recall From Setup side-menu button.
b. Use the Multipurpose knob to recall the setup from the memory location
(1-10).
6. To recall (load) setup data from a file on the USB drive:
a. Push the Recall From USB side-menu button.
b. Highlight the setup file (*.SET) to load.
c. Push the Multipurpose knob or the Recall side-menu button. The
oscilloscope loads and implements the settings.
Recalling waveform data
Use this procedure to recall (load) waveform data from an external .ISF file to
load into a reference memory location and display on the oscilloscope. The
oscilloscope can only load .ISF waveform data files.
1. Install a USB drive that contains the .ISF waveform data file.
2. Push the Save Recall front-panel button.
3. Push the Action side-menu button.
4. Use the Multipurpose knob to select and click Recall Waveform.
5. Push the To side-menu button.
6. Select and click Ref1 or Ref2.
Recalling data
134 TBS1000C Series Oscilloscopes User Manual
