Tektronix TBS1000C Series User Manual

Recalling data
Recalling oscilloscope setup information
Use this procedure to recall (load) oscilloscope settings from a memory location
or external file and set the oscilloscope to those settings.
You can recall (load) saved setup data to quickly configure the oscilloscope to
take a certain measurement. A setup file contains most of the oscilloscope
settings, including vertical, horizontal, trigger, cursor, and measurement
parameters. It does not include communications information, such as GPIB or
LAN configuration.
1. (Optional) Install a USB drive to recall the setup data from a file on the USB
drive.
2. Push the Save Recall front-panel button.
3. Push the Action side-menu button.
4. Use the Multipurpose knob to select and click Recall Setup.
TBS1000C Series Oscilloscopes User Manual 133
