Tektronix TBS1000C Series User Manual

The default oscilloscope settings Default Setup
The following table lists the oscilloscope settings that are applied when you push
the Default Setup button.
NOTE. When you push the Default Setup button, the oscilloscope displays the
channel 1 waveform and removes all other waveforms.
Function Setting and value
Acquire Mode: Sample
Record length: 2000 points
Cursors Off
Source: Ch1
Display Persist: Auto
Mode: YT
Backlight: 100%
Graticule: On
FFT Source wfm: On
Vertical Units: dBv RMS
Window: Hanning
Horizontal Scale (time per major horizontal division): 4.00 μs/div
Delay: On
Trigger position: 0.00 s
Math waveform Source 1: Ch1
Source 2: Ch2
Operation: + (add)
Measurements Source: Ch1
Selected measurements: None
Trigger Type: Edge
Source: Ch1
Coupling: DC
Slope: Rising
Level: 0.00 V
Mode: Auto
USB Device Port Connect to Computer
Vertical (all channels) Coupling: DC
Invert: Off
Bandwidth: Full
Voltage probe attenuation: 10X
Baseline position: 0.00 V
Scale (volts per major vertical division): 1.00 V
