8. Push -More- Page 1/2 side-menu button.
9. Push the Update Firmware side-menu button. Screen shows Update
Firmware message.
10. Turn the Multipurpose knob to select Yes, then click the Multipurpose
knob to install the firmware.
11. Follow the on-screen instructions.
NOTE. Do not power off the oscilloscope or remove the USB flash drive until
the oscilloscope finishes installing the firmware. It displays a message saying
it is OK to turn off the oscilloscope.
12. When the firmware install is finished, power off the oscilloscope, remove the
USB drive, and power on the oscilloscope. Let the oscilloscope power-up to
the oscilloscope screen.
13. To confirm the firmware installation:
a. Push the Utility button.
b. Push the Config side-menu button.
c. Use the Multipurpose knob to select and click System Status to open
the System Status message screen.
d. Check that the software version number shown on the screen is the same
version that you just installed.
Running diagnostic tests
Use this procedure to test instrument functional modules.
NOTE. Running self test, resets the oscilloscope settings. Save the current setup to
memory or a file, if you do not want to lose the current settings.
NOTE. Remove all probes and cables from the oscilloscope inputs.
Appendices
152 TBS1000C Series Oscilloscopes User Manual
