Appendices
Installing new firmware on the oscilloscope
Tektronix releases new oscilloscope firmware to improve existing functions or
add new functions. Complete the following steps to install new firmware in the
oscilloscope.
1. Go to http://tek.com.
2. Click Downloads. In the Downloads menu, select DOWNLOAD TYPE as
Software and enter TBS1000C in the MODEL OR KEYBOARD field ad
click SEARCH.
3. Select the latest version of the software and follow the instructions to
download. Download the latest firmware for your oscilloscope on your PC.
4. Unzip the files and copy the TBS1000C.TEK file into the root folder of a
USB flash drive.
NOTE. TBS1000C.TEK file is supported ONLY for TBS1052C, TBS1072C,
TBS1102C and TBS1202C.
5. Power on the oscilloscope.
6. Insert the USB flash drive into the front-panel USB port on your
oscilloscope.
7. Push the Utility button.
TBS1000C Series Oscilloscopes User Manual 151
