Courseware on-instrument education and training
Run guided lab exercises right on your oscilloscope. Read overview theory and
procedures, and capture your lab results right there as well.
Create new course materials on a PC with separate PC-based Courseware
software, which you can download from www.tek.com/software. After you create
the course materials, you can distribute them to supported oscilloscopes using a
USB drive or from the TekSmartLab software server.
NOTE. TekSmartLab uses wireless connectivity to connect multiple oscilloscopes
and other test bench instruments to a central server and software interface.
Using The series oscilloscope with TekSmartLab requires either a Wi-Fi
Transceiver USB dongle (Option TEKUSBWIFI) or a communication box to
connect to the TekSmartLab server. See the Scope Intro topic on TekSmartLab
for more information (Help ►Scope Intro ►TekSmartLab).
You can also go to the Courseware Web page at www.tek.com/courseware to
download courseware files that others have created and uploaded to share.
NOTE. Courseware files are compressed using .zip format. Unzip the Courseware
file and copy the uncompressed files to a USB drive.
Courseware file content
information
■
A Courseware file can contain up to 12 courses, with up to 100 MB total of
course file storage available on the oscilloscope.
■
Each course can have up to 14 labs, with each lab having overview and
procedure files.
■
Courses can contain example waveforms, data results, and waveform masks
for student reference use.
■
Refer to the Courseware and TekSmartLab documentation for more
information on these applications. You can download electronic versions of
these manuals from the Tektronix Web site (www.tek.com).
Appendices
154 TBS1000C Series Oscilloscopes User Manual
