Tektronix TBS1000C Series User Manual

3. Push the Save Recall front-panel button.
4. Push the Action side-menu button.
5. Use the Multipurpose knob to select and click Save Waveform.
6. To save waveform data to internal reference memory:
a. Push the Source side-menu button
b. Select and click the waveform data source (CH1, CH2, Math, or FFT).
NOTE. The selected waveform must be displayed on the screen to save
waveform data.
c. Push the Save As side-menu button.
d. Select and click Ref1 or Ref2.
7. To save waveform data to a file on the USB drive:
a. Push the Source side-menu button
b. Select and click the waveform data source (CH1, CH2, Math, or FFT).
NOTE. The selected waveform must be displayed on the screen to save
waveform data.
Saving data
TBS1000C Series Oscilloscopes User Manual 127
