6. Push the Level side-menu button and use the Multipurpose knob to select
and click the trigger level entry method:
■
Click Level and use the Multipurpose knob to manually set the trigger
level.
■
Click Choose Preset and use the Multipurpose knob to set the trigger
level to a predefined signal logic family level (TTL, CMOS, ECL, and so
on) or to 0.
■
Click Set to 50% to set the trigger level to 50% of the signal peak-to-
peak level.
7. Push -More- Page 1/2 side-menu button.
8. Push the Coupling side-menu button and use the Multipurpose knob to
select and click the trigger coupling. See Trigger coupling on page 43.
NOTE. You can use the Trigger Level knob to immediately change the trigger
level and momentarily display a long horizontal line (or two lines for a Runt
trigger) across the waveform to show the trigger level(s) in relation to the
waveform.
Push the Trigger Level knob to immediately set the trigger to 50% of the signal
peak-to-peak level.
Trigger setup
58 TBS1000C Series Oscilloscopes User Manual
