Application Examples Selecting a nd Configuring
Measurements-
Signal Quality Tests for High Speed Devices for Upstream Testing
Selecting and Configuring Measurements-Signal Quality Tests for High
Speed Devices for Upstream Testing
Follow the steps to select measurements for High Speed Signal Quality check:
1. From the application menu, select Measurement > Select > High speed (tab).
2. Select the tests:
Eye Diagram Test
Signal Rate
EOP
Width
Rising Edge Rate
Falling Edge Rate
Monotonic Property
3. Select the Select All toggle button to select all the measurements simultaneously. Click on any
measurement button to deselect it.
88 TDSUSB2 Universal Serial Bus Measurements Package
