Introduction Conventions
Online Help. You can find the file in the Documents directory on the Optional Applications Software o n
Windows-Based Oscilloscopes DVD.Thefigures o f application menus in the PDF file are gray scale and
all of the info
rmation prints.
Conventions
Online help uses the following conventions:
Refers to the software part of the TDSUSB2 Universal Serial Bus Measurements Package as the
TDSUSB2 application or as the application.
When steps require a sequence of selections using the application interface, the ">" delimiter marks
each transition between a menu and an option. For example, one of the steps to recall a s etup file
would appear a s File > Recall.
Unit under test (UUT) refers to the USB2.0 device under test, hub under test, host under test, and
port under test.
SOF refers to the Start of Frames exchanged between the host controller and the device when the
device is connected to the host and enumerated by
the test mode software.
Related Documentation
In addition to the Online Help, you can access other information on how to operate the oscilloscope
through the following related document
s:
Instrument Information: The user manual for your oscilloscope provides general information on how
to operate the oscilloscope.
Programmer Information: The online help for your oscilloscope provides details on how to use GPIB
commands to control the oscilloscope.
TIP. You can also download the following files, which contain programmer information and examples,
from the Tektronix Web site.
Optional Applications Software on Windows-Based Oscilloscopes Installation Manual
TDSUSB2 Universal Serial Bus M easurements Package Re f erence
TDSUSBF USB2.0 Compliance Test Fixture Instructions
FormoreinformationonUSB2.0specifications, visit www.usb.org.
Refer to the Optional Applications Software on Windows-Based Oscilloscopes Installation Manu
al for the
following information:
Software warranty
TDSUSB2 Universal Serial Bus Measurements Package 5
