Tektronix TDSUSB2 User Manual

Tutorial Introduction to the Tutorial
Introduction to the Tutorial
The tutorial teaches you how to set up the application by recalling a .tsv file, take measurements, and
view the results. More operating information is available in the Operating Basics section. Before you
begin the tut
orial, you must do the following tasks:
Starting the Application
Recalling a tsv File
Starting the Application
To start the application, select File > Run Application > USB2.0 Test Package or App > USB2.0 Test
Package or Analyze > USB2.0 Test Package.
Recalling a .tsv File
The application distribution includes the .tsv files used with this tutorial. The table below shows the
types of signals that represent these waveforms.
Tsv File name
Signal type
C:\TekApplications\tdsusb2\tsv-
files\LS_SQC.tsv
Low Speed
C:\TekApplications\tdsusb2\tsv-
files\FS_SQC.tsv
Full Speed
C:\TekApplications\tdsusb2\tsv-
files\HS_sqc.tsv
High speed
C:\TekApplications\tdsusb2\tsvfiles\ in-
rush.tsv
Low/Full/High Speed
xxx
Taking a Full Speed Signal Quality Measurement
This section discusses how to take a Full Speed Signal Quality measurement, view the results, and generate
a report. To perform these tasks, the application must be installed and enabled on a supported oscilloscope.
View I
nstalling the applicat ion (see page
12) to install the application.
To take a Full Speed Signal Quality measurement, follow these steps:
1. To set the application to default values, select File > Recall Default. The application displays the
message ‘Default setup recalled successfully.’ Select OK to view a screen image showing the default
settings.
TDSUSB2 Universal Serial Bus Measurements Package 63
