Application Examples Selecting and Configuring Measurement-Resume
Selecting and Configuring Measurement-Resume
Follow these steps to select measurements for Resume measurement:
1. From the application menu, select Measurement > Select > High speed (tab).
2. Select the More button to display the following tests:
Receiver Sensitivity
Suspend
Reset from High Speed
Packet Parameter
Chirp
Resume
Reset Suspend
3. Select the Resume me asurement.
Configuring the Measurement
Follow the steps to configure the selected measurements:
1. From the application menu, select Measurement > Configure > Configure tab.
2. Configure the following options:
Option Set to
Signal Direction
Upstream, D ownstream
Source D+ Ch1-Ch4, Ref1-Ref4
D – Ch1-Ch4, Ref1-Ref4
xxx
3. Select to acquire the data.
Viewing Results-Resume Measurement
To view the results of the tests, follow these steps:
1. Run the application and from the application menu, and select Results > Summary.
98 TDSUSB2 Universal Serial Bus Measurements Package
