Operating B asics Setting Up the Software
Setting Up the Software
You can set up the application to take one or more measurements at the same time. In addition, you can
view the results as a summary, details, an eye diagram, and a waveform plot for Signal Quality checks. You
can also gene
rate the reports in one o f the three formats: Tektronix Specific, Plug-Fest and CSV formats.
The application runs on the oscilloscope. It is recommended that you connect the keyboard and the
mouse to use
the application effectively.
See Also
View the Default Setup
Selectin
g a Measurement
Configuring a Measurement
Setting Preferences
The Preferences menu consists of two tabs: General and Advanced. To access the Preferences menu,
select File > Preferences.
