Reference Preferences Paramete rs
Preferences Parameters
Parameters
Selections Default Setting
Warn if the configuration was not
changed since last run, when Run
button is pressed
On, Off On
Show the Eye Diagram automatically,
without having to press the Eye
Diagram button in the Results screen
On, Off On
Show the Waveform Plot automatically
without having to press Waveform Plot
button in the Results screen
On, Off On
Ask for Filename or Device ID before
automatically generating Reports or
Data files
On, Off Off
Automatically generate Data files
(TSV)
On, Off Off
Show the report when generated On, Off O n
Always display the waiver mask for
High Speed Near-end and Low Speed
Eye Diagrams
On, Off Off
Do Autoset Every Time
On, Off On
LS or FS device with USB2.0 silicon On, Off Off
Allow the user configuration of test
limits
On, Off Off
Prompt for the Droop Test readout
during Report Generation
On, Off Off
Packet identification by user using
cursors
On, Off Off
Modify HoldOff
250nsto12s 1.2µs
xxx
Measurement Menus
The options available under the Me asurements menu are as follows:
Select
Configure
Measurement Parameters
The next table lists the o ptions in the Select Measurements menu by area:
168 TDSUSB2 Universal Serial Bus Measurements Package
