Getting Started Compatibility
Compatibility
For information on oscilloscope compatibility
1
, refer to the Optional Applications Software on
Windows-Based Oscilloscopes Installation Manual, Tektronix part number 071-1888-XX. The manual is
also availab
le as a PDF file. The dynamic range of the probes used for Low Speed and Full Speed testing
should be at least ± 8 volts. For High Speed testing, the dynamic range should be ± 2 volts.
1
For a current
list of compatible instruments, see the Software and Drivers category on t he Tektronix Web site.
Requirements and Restrictions
You must install Java Run-Time Environment V1.4.2_02 on the supported oscilloscope.
The application uses the Math1 channel for Low Speed and Full Speed mode of operation. You will lose
any information that you have stored in the Math1 channel.
You cannot restore the oscilloscope settings if you select File > Exit from the application.
Accessories
The application include s the following standard accessories:
Optional Application Software on Windows-Based Instruments DVD
Optional Application Software on Windows-Based Instruments Installation Manual
TDSU
SB2 Universal Serial Bus Measurements Package Reference
TDSUSBF USB2.0 Compliance Test Fixture Instructions
TDSUSBF USB2.0 Compliance Test Fixture (Revision B)
Optional Accessories:
Signal Source (for Receiver Sensitivity Tests):
DTG5334 or DTG5274 or DTG5078 with a DTGM 21 Output module-Data Generator
AWG5000 series (AWG5002) or AWG7000 series
1
TDSUSBF USB2.0 Compliance Test Fixture (Revision B)
1
X5 attenuators required when using AWG models.
10 TDSUSB2 Universal Serial Bus Measurements Package
