Tektronix TDSUSB2 User Manual

Reference Configure Chirp
Configure C hirp
Parameters
Selections Default Setting
DUT Host, Device Host
Host EL_33, EL_34 EL_35 EL_33, EL_34
Source D+-Ch1, Ch2, Ch3, Ch4 Ref1, Ref2,
Ref3, Ref4 D--Ch2, Ch3, Ch4 Ref1,
Ref2, Ref3, Ref4
Ch1
Ch2
Device EL_28, EL_29, EL_31 EL_28, EL_29, EL_31
Source D+-Ch1, Ch2, Ch3, Ch4 Ref1, Ref2,
Ref3, Ref4 D–-Ch2, Ch3, Ch4 Ref1,
Ref2, Ref3, Ref4
Ch1
Ch2
xxx
Results Menus
There are no parameters for the Results Menus.
Utilities Menus
There are three Utilities menu items:
Deskew
Report Generator
TSV File Generator
Deskew
Parameters
Selections Default Setting
Source1
Ref level1 H ysteresis1
Ch1, Ch2, Ch3, Ch4
0 -100 %
0-25%
Ch1
50%
5%
Source2
Ref level2 H ysteresis2
Ch1, Ch2, Ch3, Ch4
0 -100 %
0-25%
Ch2
50%
5%
Slope
Rise, Fall Fall
Edges 1 to 50 1
xxx
TDSUSB2 Universal Serial Bus Measurements Package 173
