Introduction Welcome to the TDSUSB2 Universal Serial Bus Measurements Package
Welcome to the TDSUSB2 Universal Serial Bus Measurements Package
TDSUSB2 Universal Serial Bus Measurements Package is a Sun Java-based application that runs on the
supported instruments connected to a PC. You can use the application software with the compliance
test fixture to take the follow ing measurements:
Signal Quality
Inrush
Droop
Drop (
supported by the test fixture only)
Receiver Sensitivity
Impedance Measurement using Time Domain Reflectometry (TDR), supported b y the application
only with the test fixture
Chirp m easurements
Packet Parameter
Resume
Reset from Suspend
R
eset from High Speed
Suspend
The application runs on the oscilloscope and d isplays on the lower part of the screen. The oscilloscope
application runs on the upper part of the screen.
