Reference About Application Parameters
Reset from Suspend
Vertical Setup Horizontal Setup Trigger Setup
Ch. Pos Scale Offset Cpling
Reclen Mainscale
Trigpos
Trigtype Slope Threshhold
Trigmd
Re-
peat
State
Hold-
Off
Dis-
play
Mode
Ch1
(D+)
-3.40 .5V 0
DC
50000 1.00E-03
15%
Edge Fall 1.8 V Nor-
mal
Off
1.00
E-5
Sin(x)/x
Ch2
(D-)
-3.40 .5 V 0
DC N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
xxx
Packet Parameter
Vertical Setup Horizontal Setup Trigger Setup
Ch. Pos Scale Offset Cpling
Reclen Mainscale
Trigpos
Trigtype Slope Threshho ld
Trigmd
Re-
peat
State
Hold
Off
Dis-
play
Mode
Ch1
(D+)
0.0 0.2V 0
DC
50000 50 50 Width Fall 360E-3 Nor-
mal
Off
1.00
E-5
Sin(x)/x
Ch2
(D-)
0.0 0.2V 0
DC N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
xxx
About Application Parameters
This section describes the TDSUSB2 application parameters, and includes the menu default settings. You
should refer to the user manual for your oscilloscope for operating details of other controls, such as
front-panel buttons. The parameters for the menus and options list the selections or range of values
available for each, and include the default values.
See Also
Fil
e Menu Parameters
Save and Recall Menu Parameters
Preferences Parameters
Measurement Menus
Configure Signal Quality
Configure Inrush Current
Configure Droop
Results
166 TDSUSB2 Universal Serial Bus Measurements Package
