Operating Basics View ing Reports
Viewing Reports
Generating Reports
Viewing R eports
You can use an HTML viewer or a browser to view the Tektronix specific and Plug-Fest format reports.
You can view the .csv (Comma Separated Variable) report in a text editor, spreadsheet, database, or a data
analysis program for further analysis. You can edit the .csv file to suit your needs.
NOTE. All the reports contain the eye diagram and the waveform plot except for the reports generated
in the .cs
v file format.
See Also
Report Generator Menu Parameters
Report G
eneration Options
View Signal Quality Check Report in Tektronix SpecificFormat
Viewing Reports
Generating Reports
TSV File Generator
You can use the TSV File Generator Utility to convert a .csv (Comma Separated Variable) file to a .tsv
(Tab Separated Variable) file. To access TSV File Generator, go to the main menu and select Utilities
> TSV File Generator.
If the Input is a .csv file, t hen the application enables the CSV Waveform Sourc e area. You can select the
sources based on the Signal type. For a single-ended signal, specify the D+ and D– inputs.
You can specify the directory C:\TekApplications\tdsusb2\tsvfilegenerator for the differential signal from
where the .csv file is taken.
IftheInputisaLivesignal,youcannotaccesstheCSVWaveformSourcearea. SelecttheLive
or Ref as the source file to enable the Live Input option. You can enable the Convert option only
if you take the measurements and display the results. The default directory for the .tsv files is
C:\TekApplications\tdsusb2\tsvfiles. You can also specify the location where the tsv file is to be generated.
58 TDSUSB2 Universal Serial Bus Measurements Package
