Operating B asics Generating R eports
You can generate reports in one of the following modes:
Manual: Select the report format, the directory name, and the file to which the report is saved. Select
the Generate option to generate the report. Specify the file name for the report.
Automatic: The application generates reports automatically without user intervention as soon as
the results are calculated. Select Generate Automatic Ids to enable this option while selecting
measurements. The application uses t he prefix that you enter to generate the file. If you select the Ask
for the File
name/Device ID before automatically generating Reports/Data files check box in the File >
Preferences > General tab, you can enter the Device ID/File Name before generating t he report. If the
File already exists, the application displays a message box to confirm whether to overwrite the e xisting
report. If you select Yes, the application overwrites the report; if you select NO, you can enter a new
Device ID/File Name or cancel the report generation. The reports are generated in the following path:
C:\TekApplications\tdsusb2\report.Thefile name is prefix_001_reportformat.csv or
prefix_001_reportformat.htm.
The report contains the device ID, device de scription, date and r esult of the test. The report also contains
the following statistical values:
Maximum (Max) and Minimum (Min) values
Mean
Peak-to-peak (Pk–Pk)
Stand
ard deviation (StdDev)
Root mean square (RMS)
Population
Status (PASS/FAIL/Conditional PASS) for the selected tests
User- The application displays this value if you select the "Allow user configuration of test limits" in
the Preferences menu and set the test limits before running the measurement.
The report includes the eye diagram and the waveform plots for the Signal Quality Check. The display on
the oscilloscope screen is embedded in the Droop report.
NOTE. Automatic Report generation is not available if you select the Drop Test readout option in File >
Pref erences > Advanced tab.
See Also
Report Generator M enu Parameters
Report Generation Options
View Signal Quality Check Report in Tektronix SpecificFormat
TDSUSB2 Universal Serial Bus Measurements Package 57
