Application Examples Selecting and Conﬁguring Measurement-Suspend Measurement

Selecting and Conﬁguring Measurement-Suspend Measurement

Follow these steps to select measurements for Suspend m easurement:

1. From the application menu, select Measurement > Select > High speed tab.

2. Select the More button to display the following tests:

Receiver Sensitivity

Suspend

Reset High Speed

Packet Parameter

Chirp

Resume

Reset From Suspend

3. Select

the Suspend measurement.

Conﬁguring the Measurement

Follow the steps to conﬁgure the selected measurements:

1. From t

he application menu, select M easurement > Con ﬁ gure > Conﬁgure tab.

2. Conﬁgure the following signal direction options:

Option Set to

Signal Direction

Upstream, D ownstream

Source D+ Ch1-Ch4, Ref1-Ref4

D – Ch1-Ch4, Ref1-Ref4

xxx

3. Select to acquire the data.

Viewing R esults-Suspend Measurement

To view the results of the tests, follow these steps:

1. Run the application and from the application menu, and select Results > Summary.

108 TDSUSB2 Universal Serial Bus Measurements Package

Tektronix TDSUSB2 User Manual
