Application Examples Viewing Results-Inrush Current Test
4. Configure the following options:
Option Set to
Live/Ref Channel acquiring the signal
xxx
5. Select Run.
Viewing Results-Inrush C urrent Test
To view the results of the tests, follow these steps:
1. Run the application and from the application menu, and select Results > Summary.
2. Click any of the test result buttons to get the details of that test.
3. From the application menu, select Results > Details.
4. Click the Eye Diagram option in Results Summary or Results Details to view the Eye Diagram.
5. Click t
he Waveform Plot to view the annotated waveform plot.
Generating Reports-Inrush Current Test
To generate reports of the test results, follow these steps:
1. From the application menu, select Utilities > Report Generator.
2. Select any one of the Report formats – Tektronix Specific, Plug-Fest SpecificorC
SV format (see
page 82).
3. Select the manual report generation mode.
4. Select the Generate button to display and view the selected report format.
NOTE. You can view the Plug-Fest specific report format as HTML pages and the .csv format in Microsoft
Excel.
TDSUSB2 Universal Serial Bus Measurements Package 81
