Application Examples Selecting a nd
Configuring Mea
surements-Full Speed Signal Quality Tests for Upstream Testing
Select
ing and Configuring Measurements-Full Speed Signal Quality
Tests
for Upstream Testing
Follo
w the steps to select measurements for Full Speed Signal Quality check:
1. Select Measurements > Select > Full Speed tab.
76 TDSUSB2 Universal Serial Bus Measurements Package
