Reference Error Codes and Warnings
Error Cod es
Error Message Description
Possible Solut
ions
E103
Mismatch in th
e .tsv file
format
The .tsv file sh
ould match
the file structure mentioned
in Reference section of
this help. For
Low and Full
Speed signals, each data
record should have three
values (Time
stamp, D+,
D–). For a High Speed .tsv
file, the file should have two
columns (Ti
me, Diff). Use
a valid file
Try generatin
g the .tsv file
using .tsv File Generator
utility that is available in the
Utilities men
u
E104
Record length is more. Set
the record length to less
than XXXXX
X data points
The record l
ength is too
high for the waveform
Click the "Horiz" button
or "Horiz/Acq" Menu from
the oscill
oscope UI. Go
to Horizontal tab and
decrease the record length
Error in acquiring waveform from oscilloscope
E111 Timeout occurred while
acquiring a waveform
This is the GPIB timeout
informa
tion that appears
when the application i s
acquiring the waveform
Make sure the probe
and compliance test
fixture c
onnections are
proper. Reacquire the new
waveform
E112 Error in turning on a
channel
The application failed to
turn on
the live channel
selected as source(s)
Make sure the probe
and compliance test
fixture
connections are
proper. Reacquire the new
waveform
E113
Error in importing waveform
from i
nstrument
The operation of importing
the w a
veform from the
acquisition memory failed.
This will fail whenever there
is no
valid waveform in the
acquisition memory
Make sure the probe
and compliance test
fixtur
e connections are
proper. Reacquire the new
waveform
Pack
et Detection Warning
E201
No E
OP region found
Tes
ting will be performed
on an full USB2.0 packet,
which includes an EOP
reg
ion. If no EOP region
is found, the results might
be incorr ect since testing
wi
ll be performed on a
incomplete packet. For
Upstream signal quality
te
sting, EOP must b e
present
Try acquiring the signals
aga
in by pressing Run
button
TDSUSB2 Universal Serial Bus Measurements Package 155
