Table A-2: M200E Warning Messages, Revision C.8
Name Message Text Description
WSYSRES SYSTEM RESET Instrument was power-cycled or the CPU was reset.
DATA INITIALIZED Data storage was erased.
WCONFIGINIT CONFIG INITIALIZED Configuration storage was reset to factory configuration or
erased.
WSAMPFLOW SAMPLE FLOW WARN Sample flow outside of warning limits specified by SFLOW_SET
variable.
WOZONEFLOW OZONE FLOW
WARNING
Ozone flow outside of warning limits specified by OFLOW_SET
variable.
WOZONEGEN OZONE GEN OFF Ozone generator is off. This is the only warning message that
automatically clears itself. It clears itself when the ozone
generator is turned on.
WRCELLPRESS RCELL PRESS WARN Reaction cell pressure outside of warning limits specified by
RCELL_PRESS_SET variable.
WBOXTEMP BOX TEMP WARNING Chassis temperature outside of warning limits specified by
BOX_SET variable.
RCELL TEMP WARNING Reaction cell temperature outside of warning limits specified by
RCELL_SET variable.
4
MANIFOLD TEMP
WARN
Bypass or dilution manifold temperature outside of warning limits
specified by MANIFOLD_SET variable.
WIZSTEMP IZS TEMP WARNING IZS temperature outside of warning limits specified by IZS_SET
variable.
WCONVTEMP CONV TEMP WARNING Converter temperature outside of warning limits specified by
CONV_SET variable.
WPMTTEMP PMT TEMP WARNING PMT temperature outside of warning limits specified by PMT_SET
variable.
WAUTOZERO AZERO WRN XXX.X MV Auto-zero reading above limit specified by AZERO_LIMIT
variable. Value shown in message indicates auto-zero reading at
time warning was displayed.
WHVPS HVPS WARNING High voltage power supply output outside of warning limits
specified by HVPS_SET variable.
WDYNZERO CANNOT DYN ZERO Contact closure zero calibration failed while DYN_ZERO was set
to ON.
WDYNSPAN CANNOT DYN SPAN Contact closure span calibration failed while DYN_SPAN was set
to ON.
REAR BOARD NOT DET Rear board was not detected during power up.
WRELAYBOARD RELAY BOARD WARN Firmware is unable to communicate with the relay board.
WFRONTPANEL FRONT PANEL WARN Firmware is unable to communicate with the front panel.
WANALOGCAL ANALOG CAL
WARNING
The A/D or at least one D/A channel has not been calibrated.
WDATAINIT
WRCELLTEMP
WMANIFOLDTEMP
WREARBOARD
1
Optional equipment only
